This paper presents a simplified dc bias injection circuitry as a part of an automated data acquisition system for soft magnetic materials characterization. Modified from the existing method for minimizing the reflected voltage on the dc bias injection circuitry, we designed a setup that only requires one current measurement. It enables rapid and fully automated data acquisition across a wide frequency, flux density, excitation waveform, temperature, and dc bias range.
